Tenda modular utilizada em eventos desportivos

Sobre o projeto

In the high-end temporary outdoor events, we may often see the more unique and attractive temporary tent structures. The modular tents of LIRI Architecture have won a lot of attention by their attraction appearance.

The modular tent is a high-end product independently developed by LIRI Architecture. Through all-round innovation, it brings new structure, function, and overall experience to customers. This series of tents has two shapes, square and hexagonal, with excellent performance, appearance and structural advantages, ingeniously adopting an ingenious design similar to Rubik’s cube, with European-style cone top, fashionable dome, simple flat top shapes, completely getting rid of the limitation of architectural modeling.

The pure black aluminum alloy frame and the pure white roof design make the tent more atmospheric and fashionable. The wall is made of vacuum glass walls, and the double-layer vacuum design can effectively play the role of sound insulation and heat insulation. At the same time, the grid arrangement makes the tent more stylish. If you have other needs, you can also choose ABS hard walls. Optional; the ground adopt cassette wooden flooring to better ensure the flatness of the ground and present the exquisite sense.

In addition to the appearance design, the modular tent also has obvious advantages compared with ordinary temporary tents
1. The beams of the tent also have the function of drainage channels, and the water from the eaves can be discharged from the beams through the columns to avoid rainwater dripping directly from the eaves;
2. The joint of multiple modular tents can share the uprights and beams, so it can realize seamless connection and unlimited expansion.
3. The hot-dip galvanized steel connector adopts CNC engraving technology, as well as the flower-shaped corner.

Due to its unique appearance and exquisite design, modular tents are now commonly used for temporary semi-permanent or permanent outdoor exhibition halls, Sports events, VIP lounges, etc.

Therefore, in general, in various commercial purposes, in order to highlight the style and strength of the enterprise, this architectural form can be flexibly matched with different walls and roofs to fit in the environment.

Modular Tent Series Specifications
Largura do vãoAltura lateralAltura da cumeeiraPerfil principal
5 m3 m3.9m150x150x2.5m (4 - channel)
6 m3 m4.2m150x150x2.5m (4 - channel)
8 m3 m4,4 m150x150x2.5m (4 - channel)
9 m
3 m4.6M150x150x2.5mm
10 m3 m4,8 m150x150x2.5m (4 - channel)
Características

Perfis da estrutura: alumínio extrudido 6061/T6 (15HW) de alta resistência

Revestimento em tecido: tecido de poliéster de alta qualidade com duplo revestimento de PVC; impermeável 100%; ignífugo de acordo com as normas DIN4102 B1, M2 e CFM; resistente aos raios UV, resistente ao rasgo, com capacidade de autolimpeza, etc.

Conectores: aço resistente galvanizado a quente

Faixa de temperatura admissível: de -30 °C a +70 °C

Resistência ao vento: máx. 100 km/h

Carga de neve: 75 kg/m² (a neve não se acumula com um telhado de grande inclinação)

Fácil de montar e desmontar

Sem postes no interior, 100% do espaço interno disponível
